TransTel AH-99PN

The TransTel AH99-PN Single Line Telephone is ideally suited to both Hospitality, as a hotel room phone, and Business applications where a single line phone with special features is an advantage.

The AH99-PN features 10 programmable memory keys that can be custom configured for services in Hospitality applications for example Operator, Front Desk, Voice Mail, Room Service, …and a variety of other services. In Business applications, these keys can represent access to system features or they may store frequently dialled telephone numbers. The Hook Delay feature can prevent putting a call on hold in the PABX by accident.

The AH99-PN is an easy-to-operate and affordable single-line telephone. It features hands-free capability, and message-waiting indication, and is wall mountable if required.

Data Sheet

User Manual

Features :

  • Be-Paged Function is available for TransTel and Hybrex systems.
  • Flash Time selectable
  • Handsfree
  • Hook Delay
  • Mute
  • Pause
  • Redial
  • Ringer Volume Selectable
  Specifications :       Features :
  •  5 Function Keys.
  • 10 One-Touch Dial Memory Keys.
  • Dial Signal DTMF / Pulse.
  • Flash Time: 100mS / 300mS / 600mS
  • Lamp Indicators :
    • Message Waiting – DC 90V.
    • Incoming Call
    • Mute Mode
    • Handsfree Mode
  • Ringer Volume: Hi / Med / Lo, 3 levels.
  • Accessories: Line Cord / curly cord.
  • Be-Paged Function is available for Hybrex GDS systems.
  • Flash Time selectable
  • Handsfree
  • Hook Delay
  • Mute
  • Pause
  • Redial
  • Ringer Volume Selectable

Physical :

  Dimension (L x W x H)     215 x 160 x 100mm
  Weight     800g
  Body Material     ABS
  Colour    Black
  Mounting     Desk-mount or Wall-mount
